All drawings are produced in ACAD and can be ported to various other formats if required. Standard drawings includes: general arrangements and layouts, sheet metal manufacturing drawings, single line and full control schematics as built drawings and FAT documentation.
Our in-house design capability includes qualified and experienced electrical engineers with capabilities to complete a full range of custom designed and manufactured switchboards, motor control centres (MCC) and control panels. Refer our “products page”.
Macquarie offers and full range of services from function description development to network design and configuration, PLC, HMI and SCADA programming, functional testing and onsite commissioning. We currently actively work with all the leading brands of PLC and SCADA software.
Macquarie can coordinate the installation of your electrical installation, from design through to material and labour supply, testing and commissioning. OHS&IM and Australian Standard compliance are then assured.
